NEW DWARF SIGNAL - PART TWO
by Ray Huber, Division One - NCR, NMRA
Forget the whole idea, I don't think so! I started this project and I will finish it. By now, you have seen the article, My Favorite Detector in the Feb Train Order, and Part One of the New Dwarf Signal in the last Train Order. Let's be honest, I know very little about electronics. However, it was this hobby we all enjoy that kindled an interest that has allowed me to pursue that interest to a level where I'm comfortable in sharing what I've learned with you. So, what I plan to do now is tie all of the pieces together in the hope they will make sense and you will have something useful to work with. If nothing else, maybe you can use bits and pieces of what you've seen on your own layout.
Let's start by looking at the flasher circuit I talked about last month. There simple, cheap and it does not need to be yellow. As a matter of fact, if you go to YouTube and type in, LED flasher, you'll be overwhelmed with videos on how to make your own. Following are two samples of the many I've seen on YouTube. Yes, you will need to get some parts, know the difference between plus and minus, and be able to solder. Of note, these circuit operates on 12VDC. That's the standard accessory voltage for the Toledo & Maumee Valley RR.
Of all the flasher circuits I found, I've picked two (see below) that are very straight forward, and require next to no knowledge about electronics. All of the parts are listed and can be obtained from any number of US supply houses. I would stay away from the on line bulk sales outlet's in that some products may not be reliable. All of the parts shown are from US supply houses. As was pointed out on YouTube, there are counterfeit items out there!
The red lines represent hard wire connections. They are on the reverse side of the diagram you are looking at. The reverse side is also the side that has small circular soldering pads attached to it.
Each circuit board is Approx 1-1/4" x 1-5/8" in size - your choice!
It all started with a piece of perf board. As you can see, it's been divided into 4 quarters each one being approx. 1-1/4" x 1-5/8". The board can be cut bigger if you like. Components are mounted on the reverse side while all soldering is done on the copper side. NOTE: Circuits #1 & #2 as shown are actual size.
SECOND THOUGHT
As I was testing each unit, the thought occurred to me that Circuit #2 had a very high flash rate. So high that it almost seemed as if there was no pause between flashes. With that thought, I decided to compare it with Circuit #1 which had a slower flash rate. Using a really high tech method of measurement, I counted the number of flashes in 10 seconds and multiplied that number by 6. Hence I had the number of flashes per minute.
Using Circuit #2 and after 4 or 5 tries to get an average count, the math turned out to be 120 flashes per minute or 2 per second - fast. In fact, to fast for me! Of note, the Capacitor rating for #2 is 2200mf (micro farads). During my readings, I learned that the flash rate can be adjusted (up/down) by adjusting the mf value of the Capacitor. I.e., Higher mf value/slower flash rate & vice versa.
OK, let's run a test! Building a new circuit, #2a, the only change I made was to increase the value of the Capacitor from 2200mf to 4700mf. WOW - instant gratification! The flash rate dropped and after counting flashes, I came up with 60 flashes per minute which for me was acceptable.
Appling the same theory to Circuit #1, I changed the Capacitor from 1000mf to 1500mf. Because Circuit #1 was already at 60 flashes per minute., I anticipated the new rate to be slower or around 40 to 45 flashes per minute. After the change and testing it, the new flash rate for Circuit #1a averaged 45 fls/min.
All that's left now is to place any of the units along with a signal like the one/s we've just discussed on your layout. Studying the wiring diagram shown on page 4, you can see where a flasher unit/s need to be installed - assuming you want to fool around with one! For me it was a fun project and I did learn from the experience. After all, that's exactly what this hobby is all about!!
LM555 DETECTOR WITH FLASHER
And there you have it! Thanks for your time and enjoy, The World's Greatest Hobby!
